Michelson (2.5X and 5X) and Mirau (10X, 20X and 50X) Objectives Available Infinity Corrected 200mm Tube Lens Design Interferometry bives are used in non-contact optical profile measurement devices to obtain surface maps and surface measurement beters. They can be used to examine surface topography with very high precision—to within a frb of the wavelength of light. In these bives, a light beam passes through a beamsplitter, which directs the light to both the surface of the sample and a built-in reference mirror. The light reflected from these surfaces recombines and a fringe interference pattern is bed. The Michelson bives provide comparatively longer working distances, wider fields of view and larger depth of focus, whereas the Mirau bives are used in applications requiring higher magnification and/or numerical apertures. Use of the Nikon 200mm tube lens (#58- 520) allows these bives to be integrated to a C-Mount camera. Magnification 2.5X 5X 10X 20X 50X 100x Numerical Aperture 0.075 0.13 0.30 0.40 0.55 0.7 Working Distance 10.3mm 9.3mm 7.4mm 4.7mm 3.4mm 2mm Focal Length 80.0mm 40.0mm 20.0mm 10.0mm 4.0mm 2mm Resolving Power 3.7μm 2.1μm 0.92μm 0.69μm 0.50μm 0.40μm Depth of Focus 48.6μm 416.2μm 3.04μm 1.71μm 0.90μm 0.56μm Field of View Eyepiece, 25 Diameter Field 10.0mm 5.0mm 2.5mm 1.25mm 0.50mm 0.25mm Eyepiece, 20 Diameter Field 4.4mm 2.2mm 2mm 1mm 0.22mm 0.2mm 2/3" Sensor Camera (H x V) 3.52 x 2.64mm 1.76 x 1.32mm 0.88 x 0.66mm 0.44 x 0.33mm 0.18 x 0.13mm 0.011 x 0.08mm 1/2" Sensor Camera (H x V) 2.56 x 1.92mm 1.28 x 0.96mm 0.64 x 0.48mm 0.32 x 0.24mm 0.13 x 0.10mm 0.08 x 0.06mm Weight 440g 280g 125g 130g 150g 200g 商品名称 2.5X Nikon CF IC Epi Plan TI Interferometry Objective 5X Nikon CF IC Epi Plan TI Interferometry Objective 10X Nikon CF IC Epi Plan DI Interferometry Objective 20X Nikon CF IC Epi Plan DI Interferometry Objective 50X NIKON CF IC Epi Plan DI Interferometry Objective 100X Nikon CF IC Epi Plan DI Interferometry Objective
